Tipo Mt4-2AD 1350 (1951-1953)

Type tipo - "Mt4"
Body - 2 seat Spider/Coupe
Dry Weight - kg 530

Chasis Measures
Length - mm 2200
Track - Front - mm 1200
Track - Rear - mm 1150

Engine - tipo "2AD"
Number of Cylinders - 4
Bore - mm 75
Stroke - mm 76
displacment per Cylinder - cm3 335.59
Total Displacmnt - cm3 1342.36
Compression - 9:1
Max Power- 100 hp @ 6300 RPM
Valve Gear Twin cam, chain driven gears
Carburatoin- 2 X Weber 38 DCO3
Ignition Single spark plug, distributor
fuel Pump- electric pump
Lubrication- electric pump

Clutch
single disk

Transmission
4 forward + reverse

Chassis
Tubolar with longentudal support tubes

Front Suspention
Independent, Triangulat A-Arms,
telescopic shocks, Helical springs, anti roll-bar

Rear Suspension
Longentudunal semi indeoendent leaf-spring,
telescopic shocks *starting in 1951 - Longentudinal A-arms

Brakes
hydrolic drum brakes 4 wheels

Rims
Borrani type, spoked 5.00X15 (front) 5.50x15 (rear)

Tyres
5.0-15 (front) 5.50-15 (rear)

Fuel Tank
75 or 100 Liters

Max Speed
190 km/h
